| | Colum | Q235, Q355 Welded H Section Steel |
| Beam | Q235 ,Q355 Welded H Section Steel |
| | Purlin | Q235 C and Z purlin |
| | Q235 Angle Steel |
| Tie Rod | Q235 Circular Steel Pipe |
| Brace | Q235 Round Bar |
| Vertical and Horizontal Support | Q235 Angle Steel, Round Bar or Steel Pipe |
| | Roof System | Roof Panel (EPS/Fiber Glass Wool/Rock Wool/PU Sandwich Panel or Steel Sheet Cover) and Accessories |
| Wall System | Wall Panel (Sandwich Panel or Corrugated Steel Sheet |
| Window System | Aluminum Alloy Window/ PVC Window/Skylight |
| Door System | Sliding Sandwich Panel Door/Rolling Metal Door/PVC Door |
| Others | PVC Rainspout,Gutter etc |
| Wind Resistance Grace | 11 Grades |
| Earthquake-resistance | 7 Grades |
| Structure life span | Up to 50 years |
| Temperature | Suitable temperature -50℃~+50℃ |
| Certification | CE, SGS, ISO9001:2008, ISO 14001:2004 |
| Finishing Options | The vast array of colors and textures available |
| Paint Options | Alkyd painting, two primary painting, two finish painting(gray paint, red paint, white paint, epoxy zinc, etc.) or Galvanized. |
| All the solutions for your: Qingdao KXD STEEL STRUCTURE CO., LTD |
| Column and rafter | Tie beam (eave strut) | X Brace |
Main steel structure frame :
Material: Weld H beam or hot rolled H beam, etc
Grade:Q355 (S355JR)
Surface: Hot dip Galvanized zinc coating or Anti-rust paint, rich-zinc epoxy paint, etc
Usage: Make up the main steel structure frame | Strut (Tie beam) on eave and ridge:
Material: Round pipe or square tube, etc
Grade:Q235 (S235JR)
Surface: Hot dip Galvanized zinc coat or Anti-rust paint, rich-zinc epoxy paint, etc
Usage: Avoid the main steel structure frame shake in the length direction | X brace for the roof and wall:
Material: Steel Round bar or angle steel, etc
Grade:Q235 (S235JR)
Surface: Hot dip Galvanized zinc coat or Anti-rust paint, rich-zinc epoxy paint, etc
Usage: Make the whole structure stable, tie the whole building into one |
| Purlin & Wall girt | Corrugated steel sheet and flashing trimming | Sandwich panel |
Purlin:
Material: C/Z purlin etc
Size:80~300mm,thickness1.8~3.0mm
Grade:Q235 (S235JR)
Surface: Galvanized zinc coating
Applications: For supporting the protection structure and installing cladding panels | Single sheet:
Color: Ral. colors, optional
Thickness:0.13-0.8mm
Type:V840,V900,etc mutiple wave type
Usage: Prefabricated Building Roof or wall coverage or cladding
flashing trimming cover: To cover the ridge, wall out corner, etc, to avoid leaking air or water | Sandwich panel or insulation:
Structure two-layer PPGI surface sheets and insulation core
Type: EPS sandwich panel, Rock wool sandwich panel, Glass wool sandwich panel, PU/PIR sandwich panel, etc
Other insulation: glass wool blanket or PE foam
Applications: Fireproofing and warm insulation
Advantage: Removable, lightweight, and easy to install |
| Before Quote Need To Confirm Qingdao KXD STEEL STRUCTURE CO., LTD |
1. Location (Where will it be built): __Country __area
2. Size ( length* width* height ): __ m*__ m*__ m*
3. Wind speed: __KM/H
4. Snow load: __KG/m²
5. Anti-earthquake: __level
6. Brickwall needed or not? If yes, 1.2m high or 1.5m high?
7. Thermal insulation: If yes, fiberglass wool, rock wool, PU sandwich panels will be suggested; if not, the metal steels will be ok. The cost of the latter will be much lower than that of the former.
8. Door quantity & size: __units __(width)m __(height)m
9. Window quantity & size: __units __(width)m __(height)m
10. Crane needed or not: If yes, __units, crane max lift height __m, max lift capacity __tons.
Support and Services:
1. We supply one-stop service from the 3D model, design drawing, and construction drawing, and online technical support, to return and replacement.
2. With a patented pallet, it is easy to load and unload.
3. Nice appearance, smooth surface, and different painting color options for customized.
4. Stable and durable, could assist strong wind and heavy snow.
5. Cost-effective, low-cost, and fast construction, the materials can be recycled.
Packing and Shipping:
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to Qingdao port. And we have total 3 workshops from steel structure to wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity, partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution according to your requirements before placing order. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.
